Our this hay crop bundling machine is include the feeder , bundling rope ,hydraulic ,electric equipment ,five parts . Suitable for processingthe native grass ,wheet straw, straw,legume stalk. the machine can achieve the collecting and feeding ,bundling ,pressing ,packing ,off-loading etc .The bundled hay corn is tight outside ,loose inside ,good breathability .
Hanging automatic pick-up balers our farmers according to the requirements and expertise combined with similar products, and improved by a new type of universal automatic feed pickup balers. It can automatically pick up forage, balers and put the bundle, it is capable of a variety of wheat straw, rice straw, forage baling operation, matching power 18-50 horsepower four-wheel tractors, mainly by the pick of the crop, grass playing roller chain wheel drive mechanism, rope box, lead wire rod and warning devices, hydraulic control mechanism and other components. When automatic balers lead rope, automatic picking straw, automatic balers, automatic Qiesheng make bale to leave and not messy.
Model | 9HY-8050 | 9HY-8070 | 9HY-9010 |
Matched power | 25-50HP | 25-50hp | 30-50HP |
Weight | 440Kg | 460kg | 480KG |
Capacity | 2-5km /h | 2-5km/h | 2-5km/h |
Straw weight | 15-20Kg | 25-30kg | 35-40kg |
Straw size | Φ500*700(mm) | Φ610*700mm | Φ630*930mm |
Working width (mm) | 800 | 800 | 1000 |
Driven way | P.T.O driven | P.T.O driven | P.T.O driven |
Input rotating speed(r/min) | 540 | 540 | 540 |
Tyre size | 16*6.50-8-4R | 16*6.50-8-4R | 18*8.5-6R |
SIZE(mm) | 1150*1110*1110 | 1320*1110*1200 | 1320*1320*1200 |
Cylinder number | 10 | 12 | 12 |
Selling Units:
Single item
Single package size:
120X120X120 cm
Single gross weight:
520.0 kg
Lead Time :
Quantity(Set) | 1 - 1000 | >1000 |
Est. Time(day) | 30 | To be negotiated |
shanxi water group work win Co., Ltd. mainly provides enterprises with global solutions for international trade, corporate foreign trade team hatching, operating in a new type of interconnection model, featuring multilingual overseas mother tongue promotion, and ultra-high order conversion rates. Innovative cross-border platform.
Features:
1)With advanced design and compact structure.
2)Twine auto binding system.
3)Hydraulic ejection system.
4)Bale density adjustable.
5)Simple mechanism,low mantenance.
6)The gearbox output is protected by shear bolt.
7)Hydraulic lifting system for easy ridge crossing.
8)Light and round straw bales convenient for storage and transportation.
9)Power package unit is equipped as standard for tailagate opening.
10)11 years rich manufacturing experience of hay baler.
1). How to order?
-After you decide to purchase, we will send you proforma invoice with our bank information, For single set, your machine can be delivered within 5 days after we getting the deposit, we will send to the port and deliver to you by sea.
2). Related products?
-We have disc moer, which can cut grass, alfalfa, corn stalk, into lines.
-Hay rake tedder to ted and rake your materials.
-Round or square baler to bale these materials into bales.
-Hay wrapper can wrap your bales for long time storage.
3). What size of tractor suitable for this baler?
-If your tractor has above 20-50HP (for RXYK-0850 and RXYK-0870), RXYK-1200 need above 45HP, then it will operate our compact hay balers.
-If your tractor has independent or live PTO you can operate our compact hay balers.
