404 model 25HP jinma tractor small agriculture tractor with EC CE emark
Product Description
The main characteristic has: Adopt new Zhejiang firewood diesel , reliability well , has bigger moment of torsion reserve system;
10 inches of pair of effects clutch; The speed change box archives place is 4 X (2 + 1); Detached driving force of postposition exports a device ,
drive balances , bears the weight of a force big; The entire hydraulic pressure front wheel adopt the independent oil road gets lost , gets lost nimble , reliable , saves labour;
The force moment adopt disk brake , braking is big , the braking is reliable; Adopt
Tractor model | LYH404 | |
Pattern | 4×2 (four-wheel drive) | |
Outlook size mm | Long (in front of belt counterweight) | 3513 |
Width | 1823 | |
High (to air vent) | 2130 | |
Spread of axies (mm) | 1880 | |
Front wheel tread (mm) | 1250 | |
Rear wheel tread (mm) | 1200-1500 (commonly used 1300) | |
Smallest gully (mm) | 325 | |
Agronomy gully (mm) | 375 | |
Changes radius (mm) | Unilateral brake | 3.4 |
Unilateral does not apply the brake | 4.1 | |
Complete machine quality (kg) | Structure quality | 1890 |
Smallest use quality | 2080 | |
First disposes | 144 | |
Latter disposes | 360 | |
Fixed force of traction (KN) | 12 | |
Engine model | 490BT | |
Demarcation power (KW) | 29.4 | |
Coupling | 10 inch dry list function or double-acting | |
Gear box | 4× (2 1) keeps off the composition type meshing wrap to shift gea | |
Speed range | 2.4-31.9 | |
Central rotation | Screw round bevel gear pair | |
Differential device | Two planetary gears, closed type | |
Differential lock | Plug type | |
Final transmission | Planet gear type | |
First driving axle | The entire seal bevel gear type (four-wheel drive type uses) | |
Transfer case | The straight tooth cylindrical gears (four-wheel drive type uses) | |
Front wheel tire specification | 6.0-16 8.3-20 | |
Trailing wheel tire specification | 12.4-28 | |
Diverter pattern | Mechanical or the entire hydraulic pressure changes | |
Brake labor | Biplate oil bath plate brake (mechanical type) | |
Hoist pattern | The half minute sets at the type | |
Ploughs the deep control mode | Strength, position control and fluctuation control | |
Suspension unit pattern | Postpositioned three point suspension | |
Dynamic output speed of spindle (r/min) | 540/760 | |
Packaging and transportation
Packaging Details
Standard packing for export
Lead Time :10days
Factory Display
Company advatage
KUIWEN GROUP WORK WIN CO., LTD. is a leading manufacturer and provider of total integrated supply chain solutions.
We offer the best agricultural equipments, garden equipments, and accessories.
Our main product lines: tractor series, agricultural cultivating machinery series, spraying series, harvesting machinery series,
postprocessing machinery series, casting and forgings series.
Our farm implements could match with domestic tractor (FOTON, YTO), and foreign famous brand tractor (JOHN DEERE, NEW HOLLAND, KUBOTA etc.)
We have a multilingual team, and many big branch factories. A regional market presence-including southeast Asia, Indonesia, Russia, Spain, Chile, Brasil, Australia etc.
Customer visit
FAQ
1 . Manufacturer or Trading Company
We are a leading tractor manufacturer for 20 years, and specialize in 30-230Hp tractors .
2 . MOQ
1 unitEnfly DQ904 versatile tractor wheel style vintage farm tractor
3 . Spare Parts
Free toolbox and easy wear parts.
4 . Shipment
We can help you arrange shipment.
5 . Delivery Time
Usually 15 days
6 . Warranty Time
Complete service system, 12 months since arrival of destination port
7 . Payment Terms
We accept 30%T/T in advance, and 70% T/T before shipping or L/C at sight.
8 . Tractor Options
Can be equipped with ROPS, Canopy, Cabin, AC Cabin, Air Brakes, Hydraulic Valve Out, Paddy Tire, Turf Tire or as per your requirements.
9 . Tractor Logo
We have our own logo. And we also can make your own logo in your order for free.
