1.we are tractor manufacturer
2.small tractor with loader and backhoe
3.we can arrange good shipping company for you
Tractor Model | LT1100 | |
Drive Type | 4×2 | |
Overall Dimension(mm) | Length | 4334 |
Width | 2038 | |
Height(to air vent) | 2925 | |
Wheel Base(mm) | Front Wheel Thread | 1385-1685 |
Rear Wheel Thread | 1620-2020 | |
Min. Ground Clearance(mm) | 470 | |
Min. Operating Weight(kg) | 3790 | |
Engine | Model | LR6B3-23 |
Rated Power(kw) | 81 | |
Rated Speed(r/min) | 2300 | |
Tires Specification | Front Tire | 6.50-20 |
Rear Tire | 16.9-34 | |
Max.Lifting Force(kn) | 19.5 | |
Max. Traction Force(kn) | 21.6 | |
Speed(km/h) | Forward | 1.58-33.69 |
Reverse | 2.41-34.67 | |
1. Adopt Xinchai diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency;
2. Double-function clutch,10 inches, high transmission capacity, reliable, comfortable manipulation;
3. Gearbox using 4 × 3(1 +1) engaging sleeve, shuttle-type gearshift, there are 12 forward gears, 12 reverse gears, reasonable
match between the gears, and have high efficiency;
4. Independent power take off device, smooth transmission, large capacity, speed (540/760, 540/1000 r/min) for selection to
meet the different operation requirements;
5. Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy;
6. Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good;
7. Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned;
8. Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio;
9. New streamlined appearance, generous, modern, fashion;
10. Control levers can be mounted at side as optional, more convenient and comfortable.
Qing zhou Group Work Win Supply Chain Co., Ltd. is a leading manufacturer and provider of total integrated supply chain solutions.
We offer the best chemical products for the orders.We have a multilingual team, and many big branch factories. A regional market
presence-including southeast Asia, Indonesia, Russia, Spain, Chile, Brasil, Australia etc.Group Work Win strives to build a long
term relationships by providing our customers with continuous and reactive support.
We aim to supply better quality products and after-sales service.
1.Why chose you?
a.We are manufacturer, our products have excellent quality and competitive price.
b.We have good after-sales services,you can find us at per 24 hours.
c.Strictly testing and checking before shipping.
2.How to deal the order?
a.Payment terms: T/T 30% as deposit, and 70% before delivery.
b.We'll show you the photos of the products and packages before you pay the balance.
3.Are you interested in dealership with local company?
Yes, we are quite interested in this business. We'd like to cooperate with some local partner to sell more World machines in local
market and supply better service.
4.What is your warranty policy?
We can supply one year warranty for our machines. We will provide parts as free within warranty. We can send engineer to customer
place if big quality problem. We can provide internet or calling service at any time.
5.How do you make our business long-term and good relationship?
a.We keep good quality and competitive price to ensure our customers benefit.
b.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
