samll tractor

samll tractor

1). Good Performance and Quality
2). 4 WD Wheeld type
3). Small farm tractor

Model			LZ304
Type			4WD Wheeled Type
(mm)Dimensions of Tractor	Length (to front ballast)		3030
	Width		1470
	Height (to the exhaust vent)		1900
	Tread	Front Wheel	1215 Fixed or 1150~1215 Adjusted
		Rear Wheel	1300 Fixed or 1300~1350 Adjusted
	Axle Base		1710
	Min.Ground Clearance		347.5
Structure weight (kg)			1130
Ballast weight (kg)	Front ballast		56
	Rear ballast		112
Rated traction force (kg)			663
Engine	Model		390/485
	Type		Vertical,3-Cylinder,Water Cooled and 4-stroke
	Rated Power(kw)		22
	Rated speed (r/min)		2400
	Fuel		Diesel
Tyre	Front Wheel		6.00-14
	Rear Wheel		9.5-24
Clutch			Dual-stage clutch
Steering			power steering
Transmission Type			8+2 or 8+8 with shuttle gearshift or 16+4 with creeper shift
Suspension Type			3-point links
PTO	Type and Rev		Semi-independent Type 540/1000
	Spline Size		F35 Rectangle Spline with 6 teeth
Structure and specification are subject to change without notice.






Wucheng Group Work Win Co.,Ltdis a leading manufacturer and provider of total integrated supply chain solutions. We offer the best chemical products for the orders.

We have a multilingual team, and many big branch factories. A regional market presence-including southeast Asia, Indonesia, Russia, Spain, Chile, Brasil, Australia etc.

Group Work Win strives to build a long term relationships by providing our customers with continuous and reactive support. We aim to supply better quality products and after-sales service.
