CE approved mini farming tractor front end loader DY840 small garden tractor

Agricultural Forklift

ISO,CE

EPA4

Farm Tractor

4WD

Gas/Diesel

0 /0

L/C

Quantity:

Send Enquiry Add To Cart
Product Details

CE approved mini farming machinery tractor

Mini garden tractor DY840 small mower tractor with CE and ROPS for sale ---Multipurpose machine, combination of telescopic loader and tractor, widely used in farming, gardenning, landscaping, miniciple works, etc. You are warmly welcomed to visit us!

 CE approved mini farming tractor front end loader DY840 small garden tractor

General Introduction:



DY series front end loader farm tractors have three models, DY620, DY840 and DY1150, width from 980mm to 1500mm offered best solution to narrow space works, and front articulated design makes the turning radius much smaller which also helps a lot. Telescopic boom offers wider usage. Front and rear output enable it can be act as loader or tractor according to different usage.





Power:



All models have separately four hydraulic wheel motor, they are real four wheel drive hydrostatic dive.



All machines adopts world famous Kubota/Perkins which guarantees the quality and meanwhile more powerful.



All the actions of the machine can be achieved by only joystick/levels, buttons and switches, reasonable arrangements of all the controls makes the operating biggest comfortable.



Thanks to the quick coupling system, you can change into different attachments in just one minute, which is very simple and convenient.



We always take customers’ any possible needs into consideration, there’s cigar-lights on each machine.



We equipped window hook for the closed cabin so that the window can be opened a bit and offer better ventilation

Model

DY840

Dimension (LxWxH)

2600 X1240 X 2100mm

Max. reach(boom extended)

3000mm

Max. reach(boom retracted)

2480mm

Bucket capacity

450L

Rated loading capacity

850kg

Tipping load

1300kg

Min. turning radius

2065mm

Turning angle

450

Speed

0-12 km/h

Weight

1600 kg

Standard tire

26X12-12

Tire pressure

2.8 bar

Oil tank capacity

40L

Pressure

190bar

Working oil flow

33.5L/minx2

Tracking oil flow

78L/min

Oil model(mineral oil)

L-HL46

Engine brand

Yanmar/Kubota

Engine type

4 cylinder, water cooling

Rated power/speed

24.5 Kw/2800 r/min

Fuel tank capacity

23L

Battery

60Ah, 12V



Mini garden tractor DY840 small mower tractor with CE and ROPS for sale with sweeper



CE approved mini farming tractor front end loader DY840 small garden tractor



Mini garden tractor DY840 small mower tractor with CE and ROPS for sale ---rear hydraulic output and 3 point hitch



  Mini garden tractor DY840 small mower tractor with CE and ROPS for sale---telescopic boom



 CE approved mini farming tractor front end loader DY840 small garden tractor
