| products model | 264(260) | 284(280) | 304(300) | 354(350) | 404(400) | 454(450) |
| General Specification | ||||||
| wheel drive | 4×4(4×2) | |||||
| Dimension(L*W*H)mm | 3350×1500×1860 | |||||
| Weight(KG) | 1210-1380 | |||||
| Front Wheel Tread (mm) | 970,1200,1300adjustable | |||||
| R Wheet Tread (mm) | 1000,1200,1300 unlimited adjustable | |||||
| Wheet Base(mm) | 1750 | |||||
| Minimum Land Clearance(mm) | 330(340) | |||||
| Gear Shifts | 8F+2R | |||||
| Tyre Size | 9.5-24/650-16(9.5-24/550-16) | |||||
| Engine specification | ||||||
| Brand | JD2100 | JD2102/LD385 | JD390/LD390/390/YD485 | JDM490/LD4L22/YD485 | JDM490/LD4L23490 | JDM490 |
| Type | water cooled ,vertical ,4 stroke and direct injection | |||||
| Rated power(kW) | 19.1 | 20.58 | 22.06 | 25.7 | 29.4 | 33.1 |
| Rated Revolution(r/min) | 2300/2400 | |||||
| Start Way | Electricity start | |||||
| Transmission Box | (4+1)×2shifts | |||||
| Clutch | single chip,dry friction constant conjunction,double clutch | |||||
| PTO Speed | 6spline 540/720 | |||||
